With a team of extremely dedicated and quality lecturers, cst microwave studio tutorial will not only be a place to share knowledge but also to help students get inspired to explore and discover many creative ideas from themselves. Time Domain (FIT) Solver TST PBA Transient, low memory, broadband solution Conformal meshing (PBA, TST) Support for multi-GPU, MPI+GPU.
#CST MICROWAVE STUDIO TRANSIENT SOLVER SETTINGS FULL#
This blog is dedicated to 3D EM Field Simulation by CSTs Microwave Studio, ANSOFTs. cst microwave studio tutorial provides a comprehensive and comprehensive pathway for students to see progress after the end of each module. version of CST Studio Suite supports the full range of Tesla products on both. Lumped capacitors are used to tune the coil to the required 63 MHz. The most versatile tool is Transient (Time) Domain Solver, which can obtain entire broadband frequency behavior of the simulated device from only one single simulation run (in contrast to the frequency step approach of many other conventional simulators. The model consists of a cylindrical shield and a typical bird-cage coil. The other aspects of MRI can be tackled with the magnetostatic solver or the magneto-quasistatic solver of CST EM STUDIO.
This simplified example only focuses on the RF part at 63 MHz in the body-coil and uses the transient solver of CST MICROWAVE STUDIO. Finally additional gradient coils, operating in the kHz range, are used for the positioning the point of resonance inside the body. The field generating so-called ”body-coil” is supposed to offer a homogeneous field distribution all over the body. The nuclear resonance itself is excited at the protons intrinsic resonance of 63 MHz (dependent on the static field) with a magnetic field rotating around the axis of the magnetostatic axis (z-axis in this example). For the MRI device used in this example this biasing magnetic field strength is 1.5 Tesla, which is a typical value for clinical MRI devices. First of all a very strong static magnetic field aligns all magnetic moments in the body.
